2. Attach a Wheel (50) to the front of the Frame

(1) with an M10 x 41mm Shoulder Patch Screw

(63).

Repeat this step to attach the other Wheel

(50).

2

1

.

I

dentify the Left Frame Cover (48), which is

marked with an “L” sticker. Orient the Left and

Right Frame Covers (48, 49) with the rounded

sides in the indicated locations.

While another person lifts the rear of the Frame

(1), attach each Frame Cover (48, 49) to the

Frame with two M4 x 16mm Screws (84).

48

R

ounded

Side

1

Rounded

Side

1

To make assembly easier, read the

i

nformation on page 5 before you begin

assembling the elliptical exerciser.

84

63

50

1

63

50

84

49
